Copy of Klima-flex Extended Adjustable 2D-Hinge 180°
Index Code:3-164
Bisagra para instalación en superficie, especialmente diseñada para puertas aisladas. La bisagra viene con una placa de fijación para puertas con espesor de lámina muy delgados. La bisagra es desmontable cuando se retira la parte inferior de la bisagra. Adjustable 3 mm en sentido vertical y horizontal.
| Download PDF | Product Data Sheet |
| Download PDF | Recommended Tightening Torque |
| Door part | Zinc die cast, zinc plated or black texture powder coated |
|---|---|
| Frame part | Zinc die cast, zinc plated or black texture powder coated |
| Mounting plate | Zinc die cast, zinc plated |
| Pin | Steel, zinc plated |
| Screw | Steel, zinc plated |
| Washer | Brass, nickel plated |
