1-002_02_45mm |
Manija giratoria Vision Estándar para cilindro de perfil de 45 mm
Index Code:1-002.02
Manija giratoria de perfil bajo para cilindro de perfil de 45 mm y mecanismo de control. La puerta se cierra girando la llave.
| Download PDF | Product Data Sheet |
| Download PDF | Industrilas cut out versions |
| Download PDF | Recommended Tightening Torque |
| Dish | Zinc die cast, black coated or fibre glass reinforced polyamide (PA6GF30) |
|---|---|
| Dust cover | TPE |
| Handle | Zinc die cast, black coated or fibre glass reinforced polyamide (PA6GF30) |
| Pivot shaft | Zinc die cast, zinc plated |
| Cutout | Version C |
|---|---|
| Classifications | IP66,NEMA 4 |
To download CAD-files, you need an Industrilas account. It only takes a minute.
Make your selections in each column to create your article number (AAAAAAABC-DDDD)
|
|
|
|
PDL = Spring loaded padlock loop retracts when handle is released.
