Klima-flex 1 Latch Unit Stainless Steel

Index Code:
2-311cd

The Klima-flex system is designed for quick and easy mounting in insulated doors. The cam can be placed anywhere on the threaded area of the shaft using counter nuts. See drawing and table below for positioning of cams and cutout. The stainless version has a special cutout seen on the drawing.

The Klima-flex latching unit is fixed with a starlock washer.

Inside option: all latching units can be completed with an inside handle, roller cam and a rod link.

Download PDF
Product Data Sheet
Download PDF
Recommended Tightening Torque
CamStainless steel 304
CollarGlass fibre reinforced Polyamide (PA6GF30)
NutStainless steel 304
ShaftStainless steel 303
WasherGlass fibre reinforced Polyamide (PA6GF30)
StandardsVDI 6022
Choose CAD format here:

To download CAD-Files for this product
1. Select CAD-format
2. Click the green cube icon to generate CAD-Files
3. Wait until the download symbol is completed
4. Click the download symbol to download

Download here:
To download CAD-files, you need an Industrilas account. It only takes a minute.
or Create Account
Max/Min Measurements for Stainless Cams on Stainless Latching Units - System KLIMA-FLEX
Latching unitCamGrip range *CamGrip range *CamGrip range *
263079-S25-G402330S07-R05A=22-38
B=42-58
2330S07-R08A=8-25
B=35-51
2330S07-R01 or 2330S07-R06A=1-17
B=43-59
263079-S30-G402330S07-R05A=27-43
B=47-63
2330S07-R08A=13-30
B=40-56
2330S07-R01 or 2330S07-R06A=6-22
B=48-64
263079-S50-G40 **2330S07-R05 **A=47-63
B=67-83
2330S07-R08A=33-50
B=60-76
2330S07-R01 or 2330S07-R06A=26-42
B=68-84
263079-S60-G402330S07-R05A=57-73
B=77-93
2330S07-R08A=43-60
B=70-86
2330S07-R01 or 2330S07-R06A=36-52
B=78-94
