Compression Latch Stainless Steel 35 mm
Index Code:6-141
Quarter-turn compression latch with an extended collar, making it suitable for thick panels. Closed and tightened with a single half-turn motion, where the first 90° turn moves the cam 90° and the following 90° turn retracts the cam 6 mm. The extended, threaded shaft allows you to place the cam along its entire length, resulting in vast adjustment possibilities. The cam is fixed with counter-nuts.
The latch is delivered assembled while the cam is ordered separately.
Non-stock item, price and delivery time upon request.
| Download PDF | Product Data Sheet |
| Download PDF | Recommended Tightening Torque |
| Counter-nuts | Stainless steel 303 |
|---|---|
| Housing | Stainless steel 304 |
| Insert | Stainless steel 303 |
| Nut | Stainless steel 303 |
| Standards | DIN EN 61373 |
|---|
