Butt Hinge Stainless steel
Index Code:6-501
Cold rolled butt hinge in stainless steel with countersunk holes. Universal left and right mounting.
| Download PDF | Product Data Sheet |
| Download PDF | Recommended Tightening Torque |
| Hinge | Stainless steel 304 |
|---|
| Notes | The J-measurement describes the biggest diameter of the countersunk - and not the diameter of the hole. We recommend any of the following screws for mounting:
|
|---|
| Choose CAD format here:
To download CAD-Files for this product |
| Download here: |
To download CAD-files, you need an Industrilas account. It only takes a minute.
Other dimensions are available on request.
